Nws yog tsim los ua kom sib haum nrog ntau hom kev siv hluav taws xob. Txawm hais tias koj tab tom siv cov roj teeb sib sib zog nqus rau kev cia hluav taws xob tawm, cov hnub ci vaj huam sib luag los siv lub zog txuas ntxiv, lossis txawm tias muaj kev sib txuas ntawm cov tshuab hluav taws xob DC sib txawv, nws tuaj yeem hloov kho thiab sib koom ua ke. Nyob rau hauv ib lub zog hybrid, qhov twg lub hnub ci zog yog supplemented los ntawm ib tug me me cua turbine, lub inverter muaj peev xwm tswj tau lub fluctuating inputs los ntawm ob qhov chaw, optimizing lub hwj chim tso zis. Nws muaj kev txawj ntse charging circuitry uas tuaj yeem kho tus nqi them raws li hom roj teeb thiab nws lub xeev them. Qhov kev sib raug zoo no tsis yog tsuas yog muab kev hloov pauv hauv lub zog tsim hluav taws xob xwb tab sis kuj tso cai rau cov neeg siv los tsim cov kev daws teeb meem uas haum rau lawv cov kev xav tau tshwj xeeb, txawm tias nws yog rau lub roob tej thaj chaw deb, chaw tshawb fawb suab puam, lossis lub nkoj caij nkoj.
Multi-Mode Operation Technology: Niaj hnub nimno inverters muaj ntau hom kev ua haujlwm kom haum rau ntau yam kev thov. Lawv tuaj yeem hloov pauv ntawm kab sib chaws-khi, off-grid, thiab cov hom fais fab thaub qab. Nyob rau hauv kab sib chaws-tied hom, lub inverter synchronizes nrog daim phiaj thiab muag ntau zog rov qab mus rau lub tuam txhab nqi hluav taws xob. Hauv hom off-daim phiaj, nws ua haujlwm ntawm nws tus kheej, tsuas yog nyob ntawm lub zog hauv zos xws li roj teeb lossis cov tshuab hluav taws xob. Lub zog thaub qab hom ncaws tawm thaum lub sij hawm daim phiaj hluav taws xob, muab lub zog thaum muaj xwm txheej ceev rau cov khoom tseem ceeb. Lub peev xwm mus seamlessly hloov pauv ntawm cov qauv no muab cov neeg siv yooj yim thiab kev ntseeg tau, ua kom cov khoom siv hluav taws xob tas li tsis hais qhov xwm txheej twg.
Lub Hoobkas muaj lub zog tshwj xeeb kev tshawb fawb cheeb tsam. Ntawm no, engineers tab tom tshawb nrhiav txoj hauv kev los koom ua ke lub zog cia nrog cov inverter zoo dua. Lawv ua hauj lwm rau kev tsim cov roj teeb tshiab chemistry, them algorithms, thiab tswj cov tswv yim los txhim kho cov kev ua tau zoo thiab kev ntseeg siab ntawm kev sib koom ua ke ntawm lub zog cia thiab kev daws teeb meem inverter.
| Qauv |
SUN-10K
|
|
Roj teeb
|
Lead-acid / Li-lon
|
|
Roj teeb Voltage
|
40~60V
|
|
DC input zog
|
13000W
|
|
MPPT
|
200-650V
|
|
PV Input Tam sim no
|
26+13
|
|
AC tso zis zog
|
10000W
|
|
Zaus thiab Voltage
|
50/60Hz; 230/400V
|
|
Kev ua tau zoo
|
＞97% |
|
Daim phiaj kev cai
|
CEI 0-21, VDE-AR-N 4105, NRS 097, IEC 62116, IEC 61727, G99, G98,
VDE 0126-1-1, RD 1699, C10-11
|
|
Kev sib txuas lus
|
RS485; YOG
|
|
Kev tiv thaiv
|
IP65
|
